T120MDP UL497A
|
|
Double
ended screw terminals Just like the kind you use on you M66 Blocks or
telephone lines up to 90-120V ring voltage.
Most Din Rail Surge suppression are expensive. If you have 48V
operating it is better to get as close as possible then settle for less. Easy
replacement as well. Quick connect, disconnect feature if replacement is
required. For a UL
shop, phone systems or fire alarm panels with two RJ31X’s, there is no substitute then this
product. You get two pair protection
for the price of one. UL497 A |
|
Specifications – Operating: Service
Voltage Circuits
Protected: Connection
Type Ground Type Installation
Configuration Band Pass
Range: Terminal
Rating, |
|
Stormins New competitive Product Snap Rail—Din Rail—Through Hole Mountable. The Cool Part is, they snap like
Lego’s Lightning Protection UL
Master Label UL96A Compliant PLC’s Home Automation would Love
this especially like Lego’s approach with all of our other low voltage UL
Listed protection including patch
panel. |
|
120VDC 130V 2 Circuits
4 wires Screw
Terminal ground lug Series 0Hz –2GHz 12awg—26aug
|
|
Specifications – Performance: Maximum
Surge Current Energy
Dissipation Joules: Capacitance
@ 1kHZ: Clamping
Response Time: Current
Limiting: Maximum
Continuous Current Maximum
Operating Voltage (MCOV Clamping
Voltage: Operation
Indicators: |
|
18,000A 212 1333 < 1 Pico
Second Yes 15mA 133 214 None |
|
Specification - Compliance UL Listed: UL File:
|
|
UL 497 A |
|
Specification - Physical Weight: Height: Length: Width: Operating
Temperature: Centigrade Maximum
Humidity Plastic: |
|
2.08 in
ounces 1.6 inches 3.1 inches 92 inches 45 85% RatingV-5 |
|
Example of
multiple assembly surge suppression racked and stacked together. Very neat and tidy. All units
are grounded by the ground bar attachment. |
